QUADRO MINI
1 LED
Stainless Seel 316L
Brass
Small asymmetrical square wall recessed LED luminaire in passivated 316L stainless steel. Disc in stainless steel 316L passivated or aged brass. Extra white tempered glass. Recessing box included. Power supply to be ordered separately.
Technical caracteristics
| Fixing : | Wall recessed |
| LED Source : | 1 LED 3-SDCM - L90B10@100.000hr |
| Color T° : | 2700K / 3000K / 4000K - Other possible temperatures, contact us. |
| Product flux : | 133lm (at 3000K-Asy_clair) |
| Optic : | Asymétrical |
| Adjustable : | No |
| Dimensions : | 86mm x 60mm |
| Power : | 1.6W / 2.1W |
| Voltage : | 500mA / 12-24VDC |
Customized IP67 connection box
Pre-cabled legth upon request
Mix color/Temperature on request
IP68 connector
IP68 connection kit
Theft-proof glass
