QUADRO MINI

1 LED

Stainless Seel 316L

Brass

Small asymmetrical square wall recessed LED luminaire in passivated 316L stainless steel. Disc in stainless steel 316L passivated or aged brass. Extra white tempered glass. Recessing box included. Power supply to be ordered separately.

Technical caracteristics

Fixing :Wall recessed
LED Source :1LED
Color T° :2700K / 3000K / 4000K
Product flux :104lm (@ 3000K-Asy_clair)
Optic :Asymétrical
Adjustable :No
Dimensions :86mm x 86mm x 60mm
Power :1.6W / 2.1W
Voltage :500mA / 12-24VDC
Customized IP67 connection box
Pre-cabled legth upon request
Mix color/Temperature on request
IP68 connector
IP68 connection kit
Theft-proof glass
